Trailed Mistblowers

Trailed Mistblower INDEPENDENT

Standard equipment1000 L1500 L2000 L3000 L
FrameReinforced steelReinforced steelReinforced steelReinforced steel
CoverAnticorrosion paintingAnticorrosion paintingAnticorrosion paintingAnticorrosion painting
TankPolyethylenePolyethylenePolyethylenePolyethylene
Hand whasing tankYesYesYesYes
Rinsisng tankYesYesYesYes
PumpDiaphragm/pistonDiaphragm/pistonDiaphragm/pistonDiaphragm/piston
Standard electric DPM regulatorAtasa simplexAtasa simplexAtasa simplexAtasa simplex
Step for access of tank opepiningYesYesYesYes
Tank opening filterYesYesYesYes
Suction filter with safety valveYesYesYesYes
Centrifugal clutch of ferodosYesYesYesYes
Get anti-drift28282828
Fan820920920920
Deflector "V"YesYesYesYes
CouplingMultiplierMultiplierMultiplierMultiplier
Road Lights KitYesYesYesYes
Wheels10,0/75-15,310,0/75-15,311,5/80-15
PTO shaft 1200 mmYesYesYesYes
Anti-pollution hydro-injectorYesYesYesYes
Protection anti-leavesYesYesYesYes
1000 L1500 L2000 L3000 L
Length (mm)4300430044004650
Widht (mm)1450163516901690
Height (mm)1510153017001800
Weight (kg)390 kg640 kg640 kg990 kg
Description
Articuled towbar
Triangular articuled towbar
Homokinetic PTO shaft
Electric DPM regulator tractor cabin
Robot cleaner
Deflector d. 900 manual Kit
Deflector d. 900 hydraulic Kit
Wheels 11,5/80-15 for 2000 l Kit
Wheels 400/60-15,5 for 2000 l Kit
Wheels 400/60-15,5 for 3000 l Kit
ModelPerfomance
AngleSpeed (R.P.M.)Flow (m3/h)H.P.
820Posición 154059.00019,6
Posición 254061.50028,3
Posición 354062.00032
DeflectorClutchNº BladesNº Gets
NoYes9 Nylon + Fibra28
ModelPerfomance
AngleSpeed (R.P.M.)Flow (m3/h)H.P.
920Posición 154078.30026,5
Posición 254081.30036,9
Posición 354083.88047,5
DeflectorClutchNº BladesNº Gets
NoYes9 Nylon + Fibra28

Images


Click on the images to expand them.
